N9030B PXA Signal Analyzer Service Guide 543
Assembly Replacement Procedures
Front Frame Assembly
Table 16-18
Item Description
1RPG Knob
2 Overlay, Keyboard
3 Front Frame Side Trim Strip (plastic, 2 ea)
4Cover Plate
5 Front Frame
6 A1A5 Main Keypad
7 Braided Gasket
8 EMI Gasket
9 A1A4 Keyboard, PCA
10 A1A2 Front Panel Control Board
11 A1A3 Liquid Crystal Display 10.6-in w/PCAP Touch
1280X768-Pixels
12 A1MP9 Display hold down (compression pad)
13 A1MP11 Display Bracket, Front Panel
14 A1MP10 Bracket front panel shield
15 A1W1 Flex Circuit, Display to Front Panel Control Board
16 A1W2 Cable Assembly, Backlight
17 A1MP14 Shield
18 W1 Cable, ribbon 68 pin, Front panel Interface to
Motherboard
