Keysight DAQ970A User Guide

Plug-In Modules at a Glance
The DAQ970A offers a complete selection of plug-in modules to provide a high quality measurement,
switching, and control capabilities. For more details, see Module Overview.
Supported modules on the DAQ970A:
l DAQM900A 20-Channel FET Multiplexer Module
l DAQM901A 20-Channel Armature Multiplexer Module
l DAQM902A 16-Channel Reed Multiplexer Module
l DAQM903A 20-Channel Actuator/General-Purpose Switch Module
l DAQM904A 4x8 Two-Wire Matrix Switch Module
l DAQM905A Dual 1:4 RF Multiplexer (50 Ω) Module
l DAQM907A Multifunction Module
l DAQM908A 40-Channel Single-Ended Multiplexer Module
Refer to the product data sheet at http://literature.cdn.keysight.com/litweb/pdf/5992-3168EN.pdf
for a complete specifications on all the supported modules.
Keysight DAQ970A User's Guide 21
1 Introduction to the Instrument

Keysight DAQ970A Specifications

General

Scan Rate	Up to 450 channels/sec
Connectivity	USB, LAN, GPIB (optional)
Display	4.3-inch color LCD
Operating Temperature	0 °C to 50 °C
Number of slots	3 slots
Measurement Types	DCV, ACV, DCI, ACI, 2-wire resistance, 4-wire resistance, frequency, temperature, capacitance
Voltmeter	6.5 digit
Resolution	22 bits
Memory	Non-volatile memory
