Keysight DAQ970A User Guide

Measurements on Multiplexer Modules
The Keysight DAQ970A supports many common measurement functions with the multiplexer module.
With any multiplexer module installed on the rear panel, press [Module] and use the knob or the front panel
arrow keys to navigate into the desired multiplexer module.
You can configure the measurement function on the selected channel by pressing [Channel] > Measure.
Selecting Off will disable the measurement function in current selected channel. No any measurement func-
tion will be displayed in the scan list on the selected channel. Default measurement function will set to DC
voltage.
Table below shows the overview of each supported multiplexer module on the measurement function. Click
on each link to see the details of each configuration step.
Measurement
function
DAQ970A multiplexer module
DAQM900A DAQM901A DAQM902A DAQM908A
Temperature - Thermocouple
√ √ √
Temperature - RTD
√ √ √
[2]
Temperature - Thermistor
√ √ √
[2]
Strain - Bridge
√ √ √ √
Strain - Direct
√ √ √
[2]
DC voltage
√ √ √ √
AC voltage
√ √ √ √
DC current
√
[1]
AC current
√
[1]
Resistance
√ √ √ √
[2]
Frequency
√ √ √ √
Period
√ √ √ √
Diode
√ √ √
Capacitance
√ √ √
Notes:
[1] Channel 21 and 22 only.
[2] 2-wire measurements only. 4-wire measurements are not supported on DAQM908A multiplexer
module.
Keysight DAQ970A User's Guide 89
[Channel] Menu Overview

Keysight DAQ970A Specifications

General

Scan Rate	Up to 450 channels/sec
Connectivity	USB, LAN, GPIB (optional)
Display	4.3-inch color LCD
Operating Temperature	0 °C to 50 °C
Number of slots	3 slots
Measurement Types	DCV, ACV, DCI, ACI, 2-wire resistance, 4-wire resistance, frequency, temperature, capacitance
Voltmeter	6.5 digit
Resolution	22 bits
Memory	Non-volatile memory
