Keysight DAQ970A User Guide

BenchVue Data Acquisition (DAQ) Software Licensing 49
3 Features and Functions 51
System Overview 53
Data Acquisition System Overview 53
Signal Routing and Switching 56
Measurement Input 58
Scanning 60
Scanning with external instruments 61
The multifunction module 62
Control Output 63
Front Panel Menu Reference 67
[Scan] Key 69
[Monitor] Menu 70
Number 70
Bar Meter 71
Trend Chart 72
Histogram 73
[Home] Menu 75
Strain Offset 75
Alarm Output 77
Help 78
User Settings 78
[View] Menu 82
Views scanned memory readings (List, Trend Chart, Histogram, Statistics) 82
View alarm queue 86
View error queue 86
View number of relay cycles 87
[Channel] Menu Overview 88
Measurements on Multiplexer Modules 89
Temperature 90
Strain 96
DC Voltage 109
AC Voltage 111
DC Current 113
Resistance 115
Frequency and Period 118
Diode 119
Capacitance 120
DAQM907A Multifunction Module - Overview 120
Digital I/O (DIO) Channels (Channel 01 and 02) 121
Totalizer Channel 124
DAC output and sense channels (Channels 04 through 07) 125
Computed Channel 128
Basic math 128
Polynomial fifth order 129
Statistics 130
Scanning with External Instruments 133
Channel Labeling 134
[Interval] Menu 134
Selecting the trigger source 135
Selecting the output trigger polarity 135
Specifying number of sweeps in the scan 136
Keysight DAQ970A User's Guide 3

Keysight DAQ970A Specifications

General

Scan Rate	Up to 450 channels/sec
Connectivity	USB, LAN, GPIB (optional)
Display	4.3-inch color LCD
Operating Temperature	0 °C to 50 °C
Number of slots	3 slots
Measurement Types	DCV, ACV, DCI, ACI, 2-wire resistance, 4-wire resistance, frequency, temperature, capacitance
Voltmeter	6.5 digit
Resolution	22 bits
Memory	Non-volatile memory
