Keysight DAQ970A User Guide

Key Description
l Overview of the scan list for the module.
l Performs a module reset.
l Module labeling.
l Saves and recalls instrument state files (.sta extension) and preference files (.prf extension).
l File management.
l Saves the readings from trend chart or histogram.
l Captures and saves the screen image.
l Instrument factory reset and system preset.
l Data logging to a USB drive on the front panel.
l Returns the instrument into local control when the instrument is in remote.
3 Features and Functions
68 Keysight DAQ970A User's Guide

Keysight DAQ970A Specifications

General

Scan Rate	Up to 450 channels/sec
Connectivity	USB, LAN, GPIB (optional)
Display	4.3-inch color LCD
Operating Temperature	0 °C to 50 °C
Number of slots	3 slots
Measurement Types	DCV, ACV, DCI, ACI, 2-wire resistance, 4-wire resistance, frequency, temperature, capacitance
Voltmeter	6.5 digit
Resolution	22 bits
Memory	Non-volatile memory
