Malvern Mastersizer 3000 User Manual

Chapter 4 Making measurements
Page 4-24 MAN 0474
 The final SOP in the list (Hydro LV - SOP 3) is used to control the clean
sequence. The dispersion unit, measurement and analysis settings for each
SOP in the list are applied in sequence when the playlist is run.
 SOP playlists can be opened and saved using the options at the top
of the SOP playlist. Playlist do not have to be saved before they are run, but a
prompt will be displayed to ask if saving the playlist.
 Once the list is set up, the sequence can be run by clicking OK.
 The new playlist will be saved into the workspace window.
When the sequence is now playing, the current SOP name is reported in the win-
dow bar of the measurement manager:
Apart from the additional playlist bar, the measurement will run in a similar way to
standard SOP measurements.

Malvern Mastersizer 3000 Specifications

General

Measurement principle	Laser diffraction
Blue laser wavelength	470 nm
Sample dispersion options	Wet and dry dispersion
Data acquisition rate	10 kHz
Particle size range	0.01 to 3500 microns
Laser type	He-Ne and solid state
Accuracy	Better than 1%
Repeatability	Better than 0.5%
Technology	Mie and Fraunhofer theories
Sample dispersion units	Hydro MV, Hydro LV, Aero S
Optical model	Mie theory
Power requirements	100-240 V, 50/60 Hz
Detector arrangement	Log-spaced array
