Operating elements for driving
3.2 Short description of the operating elements
Operating manual GMK 6400 3 112 993 en 3 - 59
12.07.2013
Lowering/raising the level
Suspension struts are pre-selected.
The movement stops after the button is released and when an end position
is reached.
Vehicle level display
The current status is shown using different
symbols:
Setting the on-road level
Display of current inclination
s
1To lower: Press button – suspension struts retract
2 To lift: Press button – suspension struts extend
à p. 5 - 62
1 Green – on-road level
2 White – no on-road driving level
3 Yellow – level change
4 Violet – error
à p. 5 - 60
– To set the on-road
level:
Press the button until the symbol (1) is green
à p. 5 - 61
1 Measuring range display
2 Inclination indicator
3 Directional indicator
à p. 5 - 62
