Manitowoc GROVE GMK 6400 User Manual

Overview
1.5 Technical data
1 - 12 3 112 993 en Operating manual GMK 6400
12.07.2013
Counterweight-
sections version A
Counterweight-
sections version B
The stability of the crane rigged with the counterweight sections delivered
has been tested.
Designation
Length x width x
height in m (ft)
Weight
in kg
1)
(lbs)
15 t base plate 5.48 x 2.50 x 1.71
(17.98 x 8.20 x 5.61)
15 000
(33 070)
each 10 t plate 1.95 x 2.45 x 0.38
(6.40 x 8.04 x 1.25)
10 000
(22 050)
each 10 t block 1.65 x 1.82 x 0.73
(5.41 x 5.97 x 2.40)
10 000
(22 050)
Designation
Length x width x
height in m (ft)
Weight
in kg
1)
(lbs)
15 t base plate 5.48 x 2.50 x 1.71
(17.98 x 8.20 x 5.61)
15 000
(33 070)
each 10 t plate 1.85 x 2.14 x 0.56
(6.07 x 7.02 x 1.84)
10 000
(22 050)
each 10 t block 1.68 x 2.21 x 0.64
(5.51 x 7.25 x 2.11)
10 000
(22 050)
1)
There may be deviations of up to ± 3% due to the manufacturing pro-
cedure.
