Operating elements for crane operation
9.2 Short description of the operating elements
9 - 64 3 112 993 en Operating manual GMK 6400
12.07.2013
Brightness sensor
Registers the brightness of the operating environment. The brightness of all
displays is automatically adjusted.
Manual input;
à p. 10 - 5.
Emergency stop switch
May only be used in an emergency.
ECOS display
Ignition on – Main menu display
Symbols with blue corner = submenu
Open submenu – Press the button next to the
symbol 1 x.
Serial number and programme version displays
–Press: Engine off – crane functions stop immediately.
Switch engages
– Turn switch while
pressing:
Switch returns to initial position – crane functions
released
à p. 10 - 18
1 Serial number
2 Current ECOS programme version – always include in the event of a
malfunction;
à p. 14 - 31
