Crane operation
11.3 Crane operation with main boom
11 - 78 3 112 993 en Operating manual GMK 6400
12.07.2013
You can set the desired engine speed (idling speed) with the button (1);
à p. 10 - 12.
You can limit the maximum telescoping speed in the
Power unit speeds sub-
menu;
à p. 11 - 107.
You can switch on the high-speed mode for a higher speed;
à p. 11 - 96.
Switching off the
telescoping
mechanism
If the telescoping mechanism is not required, it should be switched off to
avoid unintentional use.
• Press the (1) button once.
– The lamp in the button (1) will light up dimly.
– The symbol (2) is red if the telescoping mechanism is switched off.
If the control lever is assigned more than one function, the telescoping
mechanism will also be switched off if you switch on another power unit
which is assigned to the same control lever movement;
à Control lever con-
figuration
, p. 9 - 16.
