Rigging work
12.6 Outriggers
12 - 42 3 112 993 en Operating manual GMK 6400
12.07.2013
If the symbol (3) appears, this means that the slewing gear is switched on –
the symbols (1) and (2) remain grey.
• Switch off the slewing gear.
Extending/retracting outrigger beams
• Observe the safety instructions for operating the outrigger beams;
à p. 12 - 37
• Press the button below the symbol for the desired movement:
The pre-selected outrigger moves until you let go of the respective button
or until the respective end position has been reached.
1 Retract
2 Extend
