CSP−900RMM−2MD Helicopters, Inc.
Rotorcraft Maintenance Manual
Page 427
Revision 32
52-00-00
Legend (Ref. Figure 402)
1. DOOR LATCH MECHANISM (EARLY CONFIG)
2. CABIN DOOR
3. QUICK RELEASE PIN
4. DOOR STOP
5. DOOR TRACK
6. NUT
7. WASHER
8. BOLT
9. BUSHING
10. LINK
11. NUT
12. WASHER
13. WASHER
14. BOLT
15. BUSHING
16. RIVET
17. LOWER FAIRING
18. BOLT
19. WASHER
20. NUT
21. STOP PAD
22. WINDOW
23. WINDOW SEAL
24. NUT
25. PIN RIVET
26. BUSHING
27. BUSHING
28. BUSHING
29. PIVOT LUG
30. LOWER AFT CARRIAGE
31. PIN RIVE OR SCREW OR BOLT
32. WASHER (EARLY CONFIG)
33. WASHER
34. POST
35. TRACK ROLLER
36. PIN RIVET OR SCREW
37. DOOR POST
38. SPACER
39. PIN RIVET OR BOLT
40. QUICK RELEASE PIN
41. DOOR STOP
42. DOOR UPPER FITTING
43. COTTER PIN
44. WASHER
45. CLEVIS PIN
46. TOP CONNECTING TUBE
47. BOTTOM CONNECTING TUBE
48. TOP BOLT
49. COTTER PIN
50. CLEVIS PIN
51. BELLCRANK
52. CLEVIS PIN
53. CENTER CONNECTING TUBE
54. WASHER
55. SCREW
56. SCREW
57. TOP SUPPORT PLATE
58. SCREW
59. SCREW
60. INTERIOR DOOR HANDLE
61. EXTERIOR DOOR HANDLE
62. HANDLE HOUSING
63. SCREW
64. SCREW
65. SCREW
66. CLEVIS
67. JAM NUT
68. CLEVIS
69. BOTTOM BOLT
70. BOTTOM SUPPORT PLATE
71. UPPER STRIKE PLATE
72. LOWER STRIKE PLATE
73. SCREW
74. CABIN DOOR FITTING
