CSP−900RMM−2 MD Helicopters, Inc.
Rotorcraft Maintenance Manual
Page 6
Revision 14
01-00-00
9G01-001A
ROTOR SYSTEM
POWERPLANT
(ENGINE
RIGHT HAND)
POWERPLANT
(ENGINE LEFT HAND)
EMPENNAGE
ASSEMBLY
UPPER COWLING
AND FAIRINGS
POWERTRAIN
TAILBOOM
ASSEMBLY
BAGGAGE
COMPARTMENT
DOOR
ANTI-TORQUE
FAN ASSEMBLY
CABIN DOOR
LANDING GEAR
ASSEMBLY
COCKPIT
DOOR
FLIGHT
CONTROLS
FUSELAGE STRUCTURE
ASSEMBLY
COCKPIT
DOOR
CABIN DOOR
NOTAR

ANTI-TORQUE
CONTROL
VERTICAL
STABILIZER
HORIZONTAL
STABILIZER
FUEL SYSTEM
Figure 1. Helicopter − Major Components
