CSP−900RMM−2MD Helicopters, Inc.
Rotorcraft Maintenance Manual
Page 207
Revision 18
01-00-00
10. Abbreviations
For definitions of abbreviations used through
out this publication, refer to CSP-SPM,
Chapter 1.
11. IIDS Troubleshooting Abbreviations
(Ref. Table 203)
The following table provides a description of
the Integrated Instrument Display System
(IIDS) and the associated abbreviations used
in the RMM Troubleshooting Tables.
Table 203. RMM Troubleshooting IIDS Abbreviations
Secondary Display on IIDS Abbreviation
ENGINE FIRE WARNING ANNUNCIATOR (RED) ENG FIRE WARNING
ENGINE CHIPS CAUTION ANNUNCIATOR ENG CHIPS CAUTION
ENGINE OIL HIGH TEMPERATURE WARNING ANNUNCIATOR
(RED)
ENG OIL HI TEMP WARNING
ENGINE OIL HIGH TEMPERATURE CAUTION ANNUNCIATOR
(YELLOW)
ENG OIL HI TEMP CAUTION
ENGINE OIL TEMPERATURE DIGITAL DISPLAY in °C (WHITE) ENG OIL TEMP °C DD
ENGINE OIL LOW TEMPERATURE CAUTION ANNUNCIATOR
(YELLOW)
ENG OIL LO TEMP CAUTION
ENGINE OIL HIGH PRESSURE WARNING ANNUNCIATOR (RED) ENG OIL HI PRESS WARNING
ENGINE HIGH PRESSURE CAUTION ANNUNCIATOR (YELLOW) ENG HI PRESS CAUTION
ENGINE OIL PRESSURE DIGITAL DISPLAY in %PSI (WHITE) ENG OIL PRESS %PSI DD
ENGINE OIL LOW PRESSURE CAUTION ANNUNCIATOR
(YELLOW)
ENG OIL LOW PRESS CAUTION
ENGINE OIL LOW PRESSURE WARNING ANNUNCIATOR (RED) ENG OIL LOW PRESS WARNING
GENERATOR HIGH LOAD CAUTION ANNUNCIATOR (YELLOW) GEN HI LOAD CAUTION
GENERATOR %LOAD DIGITAL DISPLAY (WHITE) GEN %LOAD DD
GENERATOR OUT CAUTION ANNUNCIATOR (YELLOW) GEN OUT CAUTION
NG HIGH WARNING ANNUNCIATOR (RED) NG HI WARNING
NG HIGH CAUTION ANNUNCIATOR (YELLOW) NG HI CAUTION
ENGINE GAS TURBINE RPM%, NG DIGITAL DISPLAY (WHITE) NG DD
NG LOW WARNING ANNUNCIATOR (RED) NG LOW WARNING
TRANSMISSION AREA FIRE WARNING ANNUNCIATOR (RED) XSMN FIRE WARNING
TRANSMISSION CHIPS CAUTION ANNUNCIATOR (YELLOW) XSMN CHIPS CAUTION
