CSP−900RMM−2 MD Helicopters, Inc.
ROTORCRAFT MAINTENANCE MANUAL
Page 602
Revision 35
25-20-00
9G25−026
0.1 IN
(2.54 mm)
FIXED FITTING
ASSEMBLY
SLIDING FITTING
Figure 601. Seat EAS Inspection
(8). Examine straps for contamination, dirt,
and stains.
Do not let oil or grease get on
the straps. Petroleum products
can damage the straps.
Do not use methyl ethyl ketone
(cleaning solvent (C420)) or ace
tone (C436) to clean straps. These solutions
can damage the straps.
(a). Clean straps with a mild detergent,
warm water, and a soft-bristled
brush.
Do not dry the straps in the sun,
on or near a radiator, or with a
hot-air dryer. Damage to the fabric can oc
cur.
(b). Let air dry.
(c). Replace straps with visible particles
or stains embedded in the fabric.
B. Seat Energy Absorption System (EAS)
Inspection
(1). Measure the clearance between the
fixed fitting and sliding fitting on the
main tube on the two sides of each
cabin seat.
CAUTION
CAUTION
CAUTION
