MD Helicopters MD Explorer - Windscreen; Windscreen Washer (Optional)

CSP−900RMM−2 MD Helicopters, Inc.
Rotorcraft Maintenance Manual
Page 224
Revision 34
12-00-00
9. Windscreen
A. Windscreen Washer (Optional)
(Ref. Figure 216)
Consumable Materials
(Ref. CSP−SPM)
Item Nomenclature
C419 Alcohol, Isopropyl
N/A Deionized or Distilled Water
(1). Open Access Panel N80 (ref. Section
06-00-00).
(2). Disconnect elastic cord (1) from bottle
(2).
(3). Remove bottle (2) from nose compart
ment and tubing (3).
(4). Examine bottle (2) for cracks and
indications of leakage.
(a). No cracks or leaks are permitted.
(5). Fill bottle (2).
(a). For operation in temperatures above
325F (05C), fill with deionized or
distilled water.
Alcohol, Isopropyl (C419)
(b). For operation in temperatures equal
to or below 325F (05C), mix 50%, by
volume, isopropyl alcohol (C419) with
deionized or distilled water.
(6). Install tubing (3) thru cap of bottle (2).
(7). Install bottle (2) with elastic cord (1) in
nose compartment.
(8). Close Access Panel N80 (ref. Section
06-00-00).
2
1
9G12−013A
3
1. ELASTIC CORD (REF. IPL 53−10−00, FIG. 7)
2. BOTTLE
3. TUBING
Figure 216. Windscreen Washer
