CSP−900RMM−2MD Helicopters, Inc.
Rotorcraft Maintenance Manual
Page 203
Revision 19
25-60-10
Legend (Ref. Figure 1)
1. FORWARD BRACKET ASSEMBLY
2. AFT BRACKET ASSEMBLY
3. CAP
4. SUPPORT TUBE
5. BOLT
6. BOLT
7. WASHER
8. BUSHING
9. SUPPORT ASSEMBLY
10. SUPPORT ASSEMBLY
11. CONTROL BOX SUPPORT ASSEMBLY
12. BOLT
13. WASHER
14. BOLT
15. BOLT
16. CONTROLLER ASSEMBLY
17. BOLT
18. WASHER
19. LOCK NUT
20. BOLT
21. LOCK NUT
22. HOIST ASSEMBLY
23. STRUT ASSEMBLY
24. QUICK RELEASE PIN
25. WASHER
26. LOCK NUT
27. BOLT
28. BUSHING
29. QUICK RELEASE PIN
30. ROD END BEARING
31. LANYARD
32. SCREW
33. WASHER
34. NUT
35. SUPPORT FITTING (FWD)
36. SUPPORT FITTING (AFT)
37. BOLT
38. NUT
39. WASHER
40. BOLT
41. CLAMP (FWD)
42. CLAMP (AFT)
43. HANDLE
B. Assist Handel Installation
(Ref. Figure 1)
(1). Install fowrard clamp (41) 18 inches
from end of support tube (4) (measured
along bottom of support tube to bottom
edge of clamp) using bolts (37), washers
(39), and nuts (38).
(2). Install handle (43) into forward clamp
(41) using bolt (40), washers (39), and
nut (38).
NOTE: Adjust aft clamp (42) position to pre
vent binding occuring between clamp and
support tube (4).
(3). Install aft clamp (42) on handle (43)
using bolt (40), washers (39) and nut
(38).
(4). Secure aft clamp (42) to support tube
(4) 19.3 inched from end of support tube
(measured along bottom of support tube
to bottom edge of clamp) using bolts
(37), washers (39), and nuts (38).
C. Fairing Installation
(Ref. Figure 2)
(1). Attach upper fairing (1) to support
assemblies (2 and 3) and clip assem
blies (4, 5, 6 and 7) using screws (8) and
washers (9).
(2). Attach lower fairing (10) to support
assemblies (2 and 3), clip assemblies (4,
5, 6 and 7) and upper fairing (1) using
screws (8) and washers (9).
(3). Attach end cap assembly (11) to upper
and lower fairings (1 and 10) using
screws (8) and washers (9).
