MD Helicopters MD Explorer - Installation

CSP−900RMM−2MD Helicopters, Inc.
Rotorcraft Maintenance Manual
Page 405
Revision 35
32-00-00
2. Landing Gear (Aft) LH and RH Side
Stop−Clamp Assemblies
A. Removal
(Ref. Figure 402)
NOTE: This task is typical for the LH or RH aft
stop-clamp assemblies.
Sealing Compound (C211)
(1). Remove sealing compound (C211) from
head of bolt (10).
(2). Remove bolt (10), countersunk washer
(11), the end of jumper (4), flat washer
(12), and nut (13).
(3). Let jumper (4) hang loose until installa
tion.
(4). Open aft stop-clamp (8) to remove from
aft crosstube (1).
B. Installation
(Ref. Figure 402)
NOTE: This task is typical for the LH or RH aft
stop-clamp assemblies.
Consumable Materials
(Ref. CSP−SPM)
Item Nomenclature
C211 Sealing Compound, Corrosion Inhibitive
C247 Petroleum Wax (Preferred)
C245 Conductive Grease (Alternative)
C246 Conductive Oil (Alternative)
(1). Prepare the mating surfaces of aft
stop-clamp (8), end of jumper (4), and
aft crosstube (1) for an electrical bond
(ref. CSP-SPM, Section 20-50-00).
Petroleum Wax (C247)
Conductive Grease (C245)
Conductive Oil (C246)
(2). Apply petroleum wax (C247) or altern
atives to the mating surfaces of aft
crosstube (1) and aft stop-clamps (8).
Make sure countersunk washer
(11) is next to head of bolt (10)
before you install jumper (4). Incorrect as
sembly can cause electrical problems.
(3). Install aft stop-clamp (8) on aft
crosstube (1) with bolt (10), counter
sunk washer (11), the end of jumper (4),
flat washer (12), and nut (13).
(a). Turn aft stop-clamp (8) 7 to 13
degrees aft from the 12 o'clock
position.
(b). Make sure there is a 0.06 inch (1.5
mm) clearance between fuselage
fitting (2) and pad (9) of aft stop-
clamp (8).
(c). Torque nut (13) 70 to 90 in-lb (7.91
to 10.17 Nm) more than the run-on
torque (ref. CSP-SPM, Section
20-10-10).
(d). Remove unwanted petroleum wax
(C247) or alternatives.
Sealing Compound (C211)
(4). Environmentally seal the connection of
jumper (4) and the perimeter of aft
stop-clamp (8) with sealing compound
(C211) (ref. CSP-SPM, Section
20-50-00).
CAUTION
