CSP−900RMM−2 MD Helicopters, Inc.
Rotorcraft Maintenance Manual
Page 206
Revision 4
26-20-20
(1). Install discharge tube assembly
connector nuts to deck fitting and fire
bottle discharge port fitting. Torque
nuts (Ref. CSP-SPM).
(2). Install electrical load center (Ref.
CSP-900RMM-3, Section 96-00-00).
9. Distribution Tube Assembly
(Ref. Figure 202)
A. Distribution Tube Assembly Removal
NOTE: This task is typical for left and right
Distribution Tube Assembly removal.
(1). Remove engine cowl assemblies L260 or
R260 (Ref. Section 06-00-00).
(2). Remove screws (20), washers (21), and
nuts (22) from upper and lower support
clamps (23) and remove clamps.
(3). Loosen distribution tube assembly
connector nut (17) to deck fitting (30) or
(31) and remove distribution tube.
B. Distribution Tube Assembly Installation
NOTE: This task is typical for left and right
Distribution Tube Assembly installation.
(1). Install distribution tube assembly onto
deck fitting.
(2). Install upper and lower support clamps,
screws, washers, and nuts. Torque nuts
(Ref. CSP-SPM).
(3). Torque distribution tube assembly
connector nut (Ref. CSP-SPM).
(4). Install engine cowl assemblies L260 or
R260 (Ref. Section 06-00-00).
