CSP−900RMM−2MD Helicopters, Inc.
Rotorcraft Maintenance Manual
Page 209
Revision 35
06-00-00
Legend (Ref. Figure 206) (Cont.)
Item
No.
Removal and Installation
Permits Access ToName
Item
No.
Method
Ref.
Figure 204
TypeQuantity
Permits Access ToName
L210 Transmission Access
Door Assembly, LH
UPPER W/ NACA
INLET
Main Transmission Access,
Engine Reduction Gearbox
Housing
2
5
Hinge
Camloc
D
E
L210 Transmission Access
Door Assembly, LH
LOWER W/ NACA
INLET
Main Transmission Access,
Engine Reduction Gearbox
Housing
7 Camloc E
L220 Inlet Panel Assembly,
LH (Engine Air)
Inlet, Engine Compressor 25 Fastener Sleeve Bolt G
L240 APU/EPR Door (AFT) Auxiliary / External Power
Receptacle
1 Camloc E
L260 Engine Cowling
Assembly, LH
Engine, Engine Controls 10 Fastener Sleeve Bolt G
L262 Baggage Compart-
ment Door
Baggage Compartment,
behind trim panels; Engine
EEC’s, Wire Harness, ECS
Bleed Air Lines, Fuel Lines,
Drain Lines, Electrical Load
Center, Engine Fire
Extinguishing Bottles (optional)
1 Lever Action Handle H
L270 Exhaust Ejector Cowl
Assembly, LH
Engine Exhaust 18 Machine Screw L
