MD Helicopters MD Explorer - Cabin Seat Fabric Installation

CSP−900RMM−2 MD Helicopters, Inc.
Rotorcraft Maintenance Manual
Page 402
Revision 12
25-20-00
3
1
2
13
13
9G25−010C
8
5
5
12
4
11
10
4
6
9
9
7
5
FOUR-
POINT
RESTRAINT
NOTE: EARLY CONFIGURATION IS THREE-POINT RESTRAINT
HARDWARE PATTERN
TYPICAL
HARDWARE PATTERN
TYPICAL
13
1
3
2
1
1. BROWNLINE FITTING
2. ATTENUATION TUBE/SEAT ASSEMBLY
3. ANCHOR PLATES
4. NUT
5. WASHER
6. BOLT
7. BUSHING
8. BOLT
9. WASHER
10. WASHER
11. WASHER
12. BUSHING
13. RESTRAINT HARNESS
Figure 401. Cabin Seats/Restraint System
1
1. CABIN SEAT FABRIC ASSEMBLY
2. BOWLINE KNOT
3. CORD
4. SEAT PAN
5. TIE−DOWN STRAPS
6. SHRINK SLEEVE
Figure 402. Cabin Seat Fabric Installation
