MD Helicopters MD Explorer - Page 239

CSP−900RMM−2MD Helicopters, Inc.
Rotorcraft Maintenance Manual
Page 211
Revision 35
06-00-00
Legend (Ref. Figure 207) (Cont.)
Item
No.
Removal and Installation
Permits Access ToName
Item
No.
Method
Ref.
Figure 204
TypeQuantity
Permits Access ToName
R210 Transmission Access
Door Assembly, RH
SN014−051 W/Out
NACA INLET
Main Transmission Access,
Engine Reduction Gearbox
Housing
2
5
Hinge
Camloc
D
E
N
R210 Transmission Access
Door Assembly, RH
UPPER W/ NACA
INLET
Main Transmission Access,
Engine Reduction Gearbox
Housing
2
5
Hinge
Camloc
D
E
N
R210 Transmission Access
Door Assembly, RH
LOWER W/ NACA
INLET
Main Transmission Access,
Engine Reduction Gearbox
Housing
7 Camloc E
N
R220 Inlet Panel Assembly,
RH (Engine Air)
Inlet, Engine Compressor
Section
25 Sleeve Bolt G
R260 Engine Cowl Assem-
bly, RH
Engine, Engine Controls 11 Sleeve Bolt G
R270 Exhaust Ejector Cowl
Assembly, RH
Engine Exhaust 19 Machine Screw L
