CSP−900RMM−2MD Helicopters, Inc.
Rotorcraft Maintenance Manual
Page 3
Original
79-00-00
9G79−001−1
OIL IN HOSE
VIEW ROTATED
ENGINE OIL
PRESSURE SENSOR
ENGINE OIL
TEMPERATURE SENSOR
OIL PRESSURE SENSOR
TUBE ASSEMBLY
OIL CHIP
DETECTOR
OIL FILLER
OIL OUT
HOSE
900 CONFIG
Figure 1. Engine Oil System (Sheet 1 of 2)
