CSP−900RMM−2MD Helicopters, Inc.
Rotorcraft Maintenance Manual
Page 203
Revision 35
06-00-00
7.33 ft
(2.23 m)
33.83 ft
(10.34 m)
DIAMETER
9.33 ft
(2.84 m)
5.33 ft
(1.62 m)
34.08 ft
(10.39 m)
12.0 ft
(3.66 m)
5.91 ft
(1.80 m)
10.91 ft
(3.32 m)
40.583 ft
(12.37 m)
9.17 ft
(2.79 m)
1.25 ft
(0.38 m)
9G06-006D
Figure 201. Principal Dimensions
