CSP−900RMM−2MD Helicopters, Inc.
Rotorcraft Maintenance Manual
Page 215
Revision 35
06-00-00
Legend (Ref. Figure 210) (Cont.)
Item
No.
Removal and Installation
Permits Access ToName
Item
No.
Method
Ref.
Figure 204
TypeQuantity
Permits Access ToName
SR3 Outboard Fairing
Assembly, RH
(Endplate)
Vertical Stab Torque Tube,
Control Rod, Electrical Wiring,
Position Light
11 Screw L
S4 Thruster End Cover Attachment Bolts For Rotating
Thruster
8 Screw L
SL5 Center Access Cover,
LH (Horizontal
Stabilizer)
Wiring 10 Screw L
SR5 Center Access Cover,
RH (Horizontal
Stabilizer)
Wiring 10 Screw L
S6 Leading Edge Cover
Center
10 Screw L
SL7 Access Cover LH VSCS Actuator 10 Screw L
SR7 Access Cover RH VSCS Actuator 10 Screw L
SL8 Thruster Extension
Fairing Assembly, Left
Side
Thruster Extension
Thruster Mounting
16 Screw L
SR8 Thruster Extension
Fairing Assembly,
Right Side
Thruster Extension
Thruster Mounting
16 Screw L
