Table 1. Servicing Materials
Item
System −
Component
Servicing Material (1)
Specification
Capacity
Consumable
Item No.
Description US Metric
Environmental Control System
1 Air−Conditioning
Refrigerant
EARLY CONFIG
C806 Refrigerant,
R12
(2) 5.0 lb 2.3 kg
C815 Refrigerant
R−134A
(2) 3.5 lb 1.6 kg
1 Air−Conditioning
Refrigerant
CURRENT CONFIG
C815 Refrigerant
R−134A
(2) 2.5 lb 1.1 kg
2 Air−Conditioning
System Oil
C116 Hermetic Oil,
150CX (R12)
4.5 − 5.5
Fluid
Ounces
140 − 160
Cubic
Centimeters
C117 Hermetic Oil,
RG20, RS20,
DHPR (R−134A)
4.5 − 5.5
Fluid
Ounces
140 − 160
Cubic
Centimeters
3 Compressor
Reduction Gearbox
Oil
C106 Lubricating Oil (3) 1.0
Fluid
Ounces
30
Cubic
Centimeters
Fuel System
4 Fuel
C113 Aviation Turbine
Fuel
JP−4, JP−5
MIL−DTL−5624
146.2
Gallons (4)
158.5
Gallons
(4) (5)
+29.4
Gallons (6)
553.4 Liters
(4)
600.0 Liters
(4) (5)
+111.3 Liters
(6)
C114 Aviation Turbine
Fuel
Jet A, Jet A−1
ASTM D1655
Hydraulic System
5 Hydraulic Fluid C112 Hydraulic Fluid (7) 2.2 Quarts 2.1 Liters
6 Manifold/Reservoir
Hydraulic Fluid
C112 Hydraulic Fluid (7) 1.0 Pints 0.5 Liters
7 Optional Hand Pump
Reservoir Hydraulic
Fluid
C112 Hydraulic Fluid (7) 1.2 Quarts 1.1 Liters
Landing Gear
8 Damper Fluid C105 Hydraulic Fluid MIL−H−5606 2.3 Fluid
Ounces
70.0 Cubic
Centimeters
