MD Helicopters MD Explorer - Page 404

CSP−900RMM−2 MD Helicopters, Inc.
Rotorcraft Maintenance Manual
Page 2
Original
21-20-00
GASPER ASSY
CREW STATION
AIR DUCTING
AIR DUCTING
DOOR PILLAR PLENUM
VENT AIR SUPPLY
PLENUM
GASPER ASSY OVERHEAD
CREW STATION
AIR DUCTING
VENT FAN
DOOR PILLAR PLENUM
FRESH AIR INLET
WATER SEPARATOR
FLEXIBLE
AIR DUCTING
GASPER ASSY PASSENGER
COMPARTMENT
GASPER ASSY
PASSENGER
COMPARTMENT
GASPER ASSY
PASSENGER
COMPARTMENT
GASPER ASSY
CREW STATION
AIR DUCTING
9G21−012B
FLEXIBLE
AIR DUCTING
FLEXIBLE
AIR DUCTING
DUCT ASSY
ROOF DECK
SERIAL NUMBERS 0039-SUBSEQUENT
AIR DUCTING
CABLE HANDLE
BRACKET ASSEMBLY
GASPER ASSY
COCKPIT
AIR DUCTING
GASPER ASSY
OVERHEAD
CREW STATION
AIR DUCTING
BULKHEAD
PLENUM ASSY
GASPER ASSY
COCKPIT
Figure 1. Vent System
