CSP−900RMM−2MD Helicopters, Inc.
Rotorcraft Maintenance Manual
Page 423
Original
21-40-00
Legend (Ref. Figure 407)
1. OXYGEN HOSE CLAMP
2. INSIDE SHIELD FORWARD
3. OUTSIDE SHIELD FORWARD
4. INSIDE SHIELD STA. 166
5. OUTSIDE SHIELD STA. 166
6. INSIDE SHIELD MID
7. OUTSIDE SHIELD MID
8. INSIDE SHIELD AFT
9. OUTSIDE SHIELD AFT
10. INSIDE SHIELD VERTICAL
11. OUTSIDE SHIELD VERTICAL
12. FOAM (C801)(900 CONFIG)RUBBER (C610)(902
CONFIG)
13. ADHESIVE TAPE (C709)(900 CONFIG)GLASS FABRIC
TAPE (C710)(902 CONFIG)
14. FLEXIBLE COUPLING ASSEMBLY
15. RETAINER
16. SEAL
17. CUSHIONED SUPPORT CLAMP
18. SCREW
19. WASHER
20. NUT
21. TUBE ASSEMBLY
22. AIR TEE ASSEMBLY
23. BULKHEAD BODY FITTING
24. WASHER (TEFLON)
25. BULKHEAD NUT
26. PERMASWEDGE UNION
27. NUT, COUPLING, ALUMINUM
