CSP−900RMM−2 MD Helicopters, Inc.
Rotorcraft Maintenance Manual
Page 2
Original
25-50-00
9G25−005−1A
ROOF INSULATION PANEL
HOOK TAPE
SIDE INSULATION PANEL
HOOK
TAPE
HOOK
TAPE
HOOK
TAPE
HOOK
TAPE
HOOK
TAPE
HOOK
TAPE
CARPET
THRESHOLD
HOOK
TAPE
HOOK TAPE
HOOK
TAPE
HOOK
TAPE
Figure 1. Baggage Compartment Interior Trim (Sheet 1 of 2)
