CSP−900RMM−2 MD Helicopters, Inc.
Rotorcraft Maintenance Manual
Page 2
Revision 34
25-55-00
9G25−014C
LH AFT LANDING
GEAR FITTING
RH AFT LANDING
GEAR FITTING
RH FWD LANDING
GEAR FITTING
LH FWD LANDING
GEAR FITTING
CYCLIC STICK
MANUAL CARGO HOOK
RELEASE
CARGO HOOK
LOAD INDICATOR
ELECTRICAL CONNECTOR
MANUAL RELEASE
CABLE CONNECTION
ELECTRICAL RELEASE
CONNECTOR
AFT Saddle clamp
fwd saddle clamp
QUICK
RELEASE PIN
(SEE NOTE)
PIN LINK
CABLE
LOAD BEAM
QUICK RELEASE PIN
(SEE NOTE)
FORWARD
PIN LINK
CABLE
ELECTRIC CARGO
HOOK RELEASE
cyclic grip rotated
MECHANICAL
RELEASE LEVER
SERVICE LOOP
LINK
ASSEMBLY
LINK ASSEMBLY
note: MAKE SURE QUICK
RELEASE PIN HEAD FACES
``UP'' AFTER INSTALLATION
CARGO HOOK PLACARD
MAX WORKING
LOAD 2200 LB
(IF INSTALLED REF. SB900-073)
Figure 1. Cargo Hook System
