CSP−900RMM−2 MD Helicopters, Inc.
Rotorcraft Maintenance Manual
Page 602
Revision 34
25-55-00
INSPECT FOR CRACKS
(BOTH SIDES)
LUG
9G25-024
AFT LH SADDLE (ROTATED 90 CCW)
(AFT RH SADDLE OPPOSITE)
Figure 601. Aft Saddle Inspection
