CSP−900RMM−2 MD Helicopters, Inc.
Rotorcraft Maintenance Manual
Page 2
Revision 4
26-10-10
OVERHEAT
CONTROL
HEAT/DEFOG
BLEED AIR LINE
OVERHEAT DETECTION
CABLE
DETECTION CABLE
RUBBER GROMMET
9G26−001
Figure 1. Overheat Bleed Air Leak Detection (Heat/Defog) System
