CSP−900RMM−2MD Helicopters, Inc.
Rotorcraft Maintenance Manual
Page 421
Revision 1
28-00-00
3
4
5
16
10
12
13
11
14
9
8
7
6
2
15
9G28-037
1
LOOKING INBD RIGHT SIDE
902 CONFIG
1. FUEL FILLER CAP
2. LANYARD
3. BOLT
4. WASHER
5. FILLER NECK FLANGE
6. GRAVITY FILLER NECK
7. O−RING
8. FLEXIBLE COUPLING
9. FUEL CELL FITTING
10. O−RING
11. O−RING
12. WASHER
13. NUT
14. CHECK VALVE ASSEMBLY
15. CENTER BAFFLE CHECK VALVE (902 CONFIG)
16. RETAINER, PACKING BACKUP
Figure 407. Gravity Fill Port Filler Neck and Check Valve
