CSP−900RMM−2 MD Helicopters, Inc.
Rotorcraft Maintenance Manual
Page 456
Revision 14
28-00-00
Legend (Ref. Figure 419)
1. LH VAPOR SHROUD HOSE
2. RH VAPOR SHROUD HOSE
3. LH INTERCONNECT TEE FITTING VAPOR SHROUD
BOX
4. RH INTERCONNECT TEE FITTING VAPOR SHROUD
BOX
5. LH FUEL SHUT−OFF VALVE VAPOR SHROUD BOX
6. RH FUEL SHUT−OFF VALVE VAPOR SHROUD BOX
7. LH ENGINE FEED TUBE ASSEMBLY
8. RH ENGINE FEED TUBE ASSEMBLY
9. LH INTERCONNECT TEE FITTING
10. RH INTERCONNECT TEE FITTING
11. VAPOR SHROUD BOX CROSSFEED VALVE
(900 CONFIG − PW206A)
12. UNION FITTING
13. PAN HEAD BOLT
14. WASHER
15. NUT
16. CUSHIONED SUPPORT CLAMP
17. SPACER
18. WASHER
19. PAN HEAD BOLT
20. CROSSFEED SHUT−OFF VALVE
(900 CONFIG − PW206A)
21. LOWER LH VAPOR SHROUD HOSE
(900 CONFIG − PW206A)
22. LOWER RH VAPOR SHROUD HOSE
(900 CONFIG − PW206A)
23. LOWER LH FUEL SUPPLY HOSE ASSEMBLY
(900 CONFIG − PW206A)
24. LOWER RH FUEL SUPPLY HOSE ASSEMBLY
(900 CONFIG − PW206A)
25. BOLT
26. SHROUD BOX CAP
27. TUBE FITTING CAP
28. STRAP, TIEDOWN, ELECTRICAL
29. GROMMET, MODIFIED
30. JUMPER ASSEMBLY, ELECTRIC, BONDING, AND
CURRENT RETURN
31. CLAMP, LOOP TYPE, BONDING
32. SCREW, HEX HEAD, RECESSED, FULL THREAD
33. WASHER, FLAT
34. NUT, SELF LOCKING
