CAB HEAT
BAT HOT
BAT WRM
ROTOR
BRAKE
CABIN
DOOR
BAGGAGE
DOOR
1 HYD 2
IIDS
FIRE
CHIPS
%LOAD
FUEL
GEN
OAT
°
C
%PSI
°
C
FIRE
CHIPS
FIRE
CHIPS
NG
%PSI
°
C %PSI
°
C
%LOAD
NG
GEN
FUEL
LB
YELLOW
WHITE
B. NORMAL FUEL FLOW WITH IMPENDING ENGINE FUEL FILTERS BY-PASS
E. INDICATES BOTH FUEL SHUTOFF VALVES IN CLOSED POSITION (NOTE )
FUEL FILTER
IMPENDING
BY-PASS CAUTION
(YELLOW)
FUEL FILTER
IMPENDING BY-PASS
CAUTION
FUEL SHUTOFF
VALVE (YELLOW)
(NOTE )
FUEL SHUTOFF
VALVE (YELLOW)
(NOTE )
ÍÍ
C. INDICATES LOW FUEL PRESSURE ON BOTH FUEL BOOSTER PUMPS
OR BOTH BOOSTER PUMPS IN OFF POSITION
RED
GREEN
LEFT LOW FUEL
WARNING TICK (RED)
LOW FUEL CAUTION
SEGMENT
(YELLOW)
FUEL QUANTITY
SEGMENTS
FUEL QUANTITY DIGITAL
DISPLAY (WHITE)
D. LOW FUEL PRESSURE LEFT BOOSTER PUMP WITH NORMAL
FUEL PRESSURE ON RIGHT BOOSTER PUMP
A. NORMAL FUEL PRESSURE WITH CROSSFEED VALVE SHOWN IN
NORMAL CLOSED POSITION ON IIDS SECONDARY DISPLAY PANEL
LOW FUEL WARNING
SEGMENT (RED)
9G28-058
NOTE: THE LIGHT SEGMENT BAR(S) WILL FLASH ON THE IIDS PANEL WHEN THE VALVE
IS IN TRANSIT BETWEEN THE OPEN AND CLOSED POSITION.
LB
RIGHT LOW FUEL
WARNING TICK (RED)
Figure 607. 902 CONFIG − Fuel System IIDS Secondary Panel Display
