CSP−900RMM−2 MD Helicopters, Inc.
Rotorcraft Maintenance Manual
Page 2
Revision 1
28-10-00
9G28-064-1
SUPPLEMENTAL FILLER NECK
FUEL VENT VALVE
EXISTING MAIN FUEL CELL
FUEL VENT FLOAT/ROLLOVER VALVE
FUEL QUANTITY TRANSMITTER
SUPPLEMENTAL FUEL CELL
FUEL TRANSFER LINE
FUEL TRANSFER LINE
FUEL LEVEL CONTROL VALVE
Figure 1. Supplemental Fuel System Installation (Sheet 1 of 2)
