CSP−900RMM−2 MD Helicopters, Inc.
Rotorcraft Maintenance Manual
Page 610
Revision 35
32-00-00
9G32−018E
2
13
14
1
8
3
13 INCH
(33.02 CM)
OPTIONAL SKID TUBE STEP
13 INCH
(33.02 CM)
9
10
11
11
10
12
12
10
11
11
10
9
14
15
15
10
9
12
10
7
6
5
7
6
12 INCH
(30.48 CM)
10 INCH
(25.40 CM)
18.5 INCH
(46.99 CM)
1. SKID TUBE (REF. IPL, 32−00−00, FIG. 7)
2. PLUG
3. STEP
4. LARGE STEP
5. FORWARD ABRASION STRIP
6. WASHER
7. SCREW
8. MIDDLE ABRASION STRIP
9. BOLT
10. WASHER
11. SPACER
12. NUT
13. AFT ABRASION STRIP
14. WASHER
15. SCREW
Figure 609. Skid Tube Inspections
