Metcom Solutions MCS301 User Manual

32 Type key Page 136 of 142
MCS301 meter - product Manual 1.25 MetCom Solutions GmbH
32.2 Type key for HW version from V1.5 onwards
MCS301 - _ _ _ _ _ - _ _ _ _ _ - _ _ _ _ _ _
                Connection Type:
C                Transformer rated meter
D                Direct connected meter
               Nominal Voltage and Network Type
A               3 x 100V or 3 x 110 V (3-wire, 2 Systems)
D               3 x 220V or 3 x 230 V (3-wire, 2 Systems)
1               3 x 58/100V or 3 x 63/110 V (4-wire, 3 Systems)
2               3 x 127/220V (4-wire, 3 Systems)
3               3 x 230/400V (4-wire, 3 Systems)
5               3 x 220/380V or 230/400V (4-wire, 3 System)
W               3 x 58/100V...3x 240/415 V (4-wire, 3 Systems)
E               3 x 58/100V...3x 277/480 V (4-wire, 3 Systems)
              Nominal Current:
1              1 (2) A
2              5 (6) A
3              5//1 A or 1 (6) A
4              1 (10) A
5              5 (10) A
A              5 (60) A
B              5 (80) A
C              5 (100) A
E              10 (60) A
F              10 (80) A
G              10 (100) A
             Frequency:
1             50 Hz
2             60 Hz
            Accuracy Class:
2            +A energy, cl. 0.2S (EN 62053-22)
C            +A energy, cl. 0.5S, C (EN 62053-22, EN50470- 3)
B            +A energy, class 1, B (EN 62053-21, EN50470-3)
A            +A energy, class 2, A (EN 62053-21, EN50470-3)
           Measured Quantities:
1           Active energy only
2           Active energy and reactive energy
3           Active, reactive, apparent energy
          Customer interface:
0          No customer interface
C          Customer interface (RJ12) *4)
         Modularity:
0         No module support
M         Slot for external communication modules
        Battery:
I        Internal battery for buffer ing real time clock
E        Internal and external battery prepared
       Communication Interface:
S       RS485 (terminals)
J       RS485 (RJ12)
R       RS485 + RS232 (terminals) *1)
D       RS485 (terminals) + Ethernet (RJ45) *2)
E       Ethernet (RJ45) only *2)
      Input / Outputs
0      No input
2      2x control inputs, 230V *3)
0     No S0 pulse inputs.
2     2x S0 pulse inputs. *3)
x    Electr. Outputs, 230V, 100 mA, (x= 0 ... 6)
x   Bistable relays, up to 10A, (x= 0 / 1)
  Additionals:
0  no Auxiliary power supply
1  Auxiliary power supply (48-230V AC/DC) *5)
2  Auxiliary power supply (24V DC)
0 No wired M-Bus
M Wired M-Bus Master (EN 13757-2)
S SynchBus
Remark:
*1) in case of using RS485+RS232 => the M-Bus interface is not available
*2) in case of using onboard Ethernet interface => no comms module support possible
*3) only control inputs or S0 inputs can be selected
*4) only Customer interface or Synch Bus can be used
*5) other values on request
