MCS301 - 3ph meter Page 39 of 142
MCS301 meter - product Manual 1.25 MetCom Solutions GmbH
8.4 Average- / min- / max- interval data
8.4.1 Last average values
Below data are calculated as average value with below characteristic in a defined interval
•
programmable interval (1..60min)
•
default interval: 10min (measuring period 3)
total L1 L2 L3
1 active demand, +P 1-0:1.25.0.255 1-0:21.25.0.255 1-0:41.25.0.255 1-0:61.25.0.255
2 active demand, -P 1-0:2.25.0.255 1-0:22.25.0.255 1-0:42.25.0.255 1-0:62.25.0.255
3 reactive demand, +Q 1-0:3.25.0.255 1-0:23.25.0.255 1-0:43.25.0.255 1-0:63.25.0.255
4 reactive demand, -Q 1-0:4.25.0.255 1-0:24.25.0.255 1-0:44.25.0.255 1-0:64.25.0.255
5 apparent demand, +S 1-0:9.25.0.255 1-0:29.25.0.255 1-0:49.25.0.255 1-0:69.25.0.255
6 apparent demand, -S 1-0:10.25.0.255
1-0:30.25.0.255 1-0:50.25.0.255 1-0:70.25.0.255
7 Voltage
1-0:32.25.0.255 1-0:52.25.0.255 1-0:72.25.0.255
8 current
1-0:31.25.0.255 1-0:51.25.0.255 1-0:71.25.0.255
9 power factor, total 1-0:13.25.0.255
1-0:33.25.0.255 1-0:53.25.0.255 1-0:73.25.0.255
10
frequency in any phase
1-0:14.25.0.255
11
THD, voltage
1-0:32.25.124 1-0:52.25.124 1-0:72.25.124
12
THD, current
1-0:31.25.124 1-0:51.25.124 1-0:71.25.124
13
1.te harmon. voltage *) 1-0:32.25.1 1-0:52.25.1 1-0:72.25.1
14
3.te harmon, voltage
1-0:32.25.3 1-0:52.25.3 1-0:72.25.3
15
5.te harmoni voltage
1-0:32.25.5 1-0:52.25.5 1-0:72.25.5
16
7.te harmon, voltage
1-0:32.25.7 1-0:52.25.7 1-0:72.25.7
17
9.te harmon, voltage
1-0:32.25.9 1-0:52.25.9 1-0:72.25.9
18
11.te harmon, voltage
1-0:32.25.11 1-0:52.25.11 1-0:72.25.11
19
13.te harmon, voltage
1-0:32.25.13 1-0:52.25.13 1-0:72.25.13
20
15.te harmon, voltage
1-0:32.25.15 1-0:52.25.15 1-0:72.25.15
21
1.te harmon., current *)
1-0:31.25.1 1-0:51.25.1 1-0:71.25.1
22
3.te harmon., current
1-0:31.25.3 1-0:51.25.3 1-0:71.25.3
23
5.te harmon., current
1-0:31.25.5 1-0:51.25.5 1-0:71.25.5
24
7.te harmon., current
1-0:31.25.7 1-0:51.25.7 1-0:71.25.7
25
9.te harmon., current
1-0:31.25.9 1-0:51.25.9 1-0:71.25.9
26
11.te harmon, current
1-0:31.25.11 1-0:51.25.11 1-0:71.25.11
27
13.te harmon., current
1-0:31.25.13 1-0:51.25.13 1-0:71.25.13
28
15.te harmon., current
1-0:31.25.15 1-0:51.25.15 1-0:71.25.15
Table 9: list of last average data
*) available with MCOR FW 1-0:01.01.25
