8.1.2 Energy measurement (3ph values) – since last demand reset
Below energy register are supported, starting always from the begin of the last demand reset.
Energy register total
1 active energy, +A 1-0:1.9.0.255
2 active energy, -A 1-0:2.9.0.255
3 reactive energy, +R 1-0:3.9.0.255
4 reactive energy, -R 1-0:4.9.0.255
5 apparent energy, +S 1-0:9.9.0.255
6 apparent energy, -S 1-0:10.9.0.255
Table 3: list of 3ph energy register with OBIS codes since last demand reset
Remark: All register can be stored as historical data.
8.1.3 Energy measurement (1ph measurement)
Below 1ph energy register data are supported (without tariff information)
Energy register L1 L2 L3
1 active energy, +A 1-0:21.8.0.255 1-0:41.8.0.255 1-0:61.8.0.255
2 active energy, -A 1-0:22.8.0.255 1-0:42.8.0.255 1-0:62.8.0.255
3 reactive energy, +R 1-0:23.8.0.255 1-0:43.8.0.255 1-0:63.8.0.255
4 reactive energy, -R 1-0:24.8.0.255 1-0:44.8.0.255 1-0:64.8.0.255
5 reactive energy, R1 1-0:25.8.0.255 1-0:45.8.0.255 1-0:65.8.0.255
6 reactive energy, R2 1-0:26.8.0.255 1-0:46.8.0.255 1-0:66.8.0.255
7 reactive energy, R3 1-0:27.8.0.255 1-0:47.8.0.255 1-0:67.8.0.255
8 reactive energy, R4 1-0:28.8.0.255 1-0:48.8.0.255 1-0:68.8.0.255
9 apparent energy, +S 1-0:29.8.0.255 1-0:49.8.0.255 1-0:69.8.0.255
10 apparent energy, -S 1-0:30.8.0.255 1-0:50.8.0.255 1-0:70.8.0.255
Table 4: list of 1ph energy register with OBIS codes
