MCS301 - 3ph meter Page 40 of 142
MCS301 meter - product Manual 1.25 MetCom Solutions GmbH
8.4.2 Last minimum values
Below data as minimum value with below characteristic in a defined interval
•
programmable calculated interval (1..60min)
•
default interval: 10min (measuring period 3)
•
minimum value over the samples of the interval
total L1 L2 L3
1 active demand, +P 1-0:1.23.0.255 1-0:21.23.0.255 1-0:41.23.0.255 1-0:61.23.0.255
2 active demand, -P 1-0:2.23.0.255 1-0:22.23.0.255 1-0:42.23.0.255 1-0:62.23.0.255
3 reactive demand, +Q 1-0:3.23.0.255 1-0:23.23.0.255 1-0:43.23.0.255 1-0:63.23.0.255
4 reactive demand, -Q 1-0:4.23.0.255 1-0:24.23.0.255 1-0:44.23.0.255 1-0:64.23.0.255
5 apparent demand, +S 1-0:9.23.0.255 1-0:29.23.0.255 1-0:49.23.0.255 1-0:69.23.0.255
6 apparent demand, -S 1-0:10.23.0.255 1-0:30.23.0.255 1-0:50.23.0.255 1-0:70.23.0.255
7 Voltage
1-0:32.23.0.255 1-0:52.23.0.255 1-0:72.23.0.255
8 Current
1-0:31.23.0.255 1-0:51.23.0.255 1-0:71.23.0.255
9 power factor, total 1-0:13.23.0.255 1-0:33.23.0.255 1-0:53.23.0.255 1-0:73.23.0.255
10 frequency in any phase 1-0:14.23.0.255
Table 10: list of last minimum data
8.4.3 Last maximum values
Below data are calculated as maximum value with below characteristic in a defined interval
•
programmable interval (1..60min)
•
default interval: 10min (measuring period 3)
•
maximum value over the samples of the interval
total L1 L2 L3
1 active demand, +P 1-0:1.26.0.255 1-0:21.26.0.255 1-0:41.26.0.255 1-0:61.26.0.255
2 active demand, -P 1-0:2.26.0.255 1-0:22.26.0.255 1-0:42.26.0.255 1-0:62.26.0.255
3 reactive demand, +Q 1-0:3.26.0.255 1-0:23.26.0.255 1-0:43.26.0.255 1-0:63.26.0.255
4 reactive demand, -Q 1-0:4.26.0.255 1-0:24.26.0.255 1-0:44.26.0.255 1-0:64.26.0.255
5 apparent demand, +S 1-0:9.26.0.255 1-0:29.26.0.255 1-0:49.26.0.255 1-0:69.26.0.255
6 apparent demand, -S 1-0:10.26.0.255 1-0:30.26.0.255 1-0:50.26.0.255 1-0:70.26.0.255
7 Voltage
1-0:32.26.0.255 1-0:52.26.0.255 1-0:72.26.0.255
8 Current
1-0:31.26.0.255 1-0:51.26.0.255 1-0:71.26.0.255
9 power factor, total 1-0:13.26.0.255 1-0:33.26.0.255 1-0:53.26.0.255 1-0:73.26.0.255
10 frequency in any phase 1-0:14.26.0.255
Table 11: list of last maximum data
