33 Technical data of the MCS301
Nominal voltage
4-wire, 3 Solutions
3-wire, 2 Solutions
3 x 58/100 V … 3x63/110V; or 3 x 230/400 V; +/-20%
or 3x58/100 … 3x240/415Vor 3x277/480V, -20/+15%
Nominal / maximum
current
Indirect Connection
Direct Connection
Short circuit current
Start-up current
1(2) A; 1(6) A; 1.5(6) A; 5(6) A; 5(10) A; 5 (15) A
5(60) A; 5(80) A; 5(100) A;
Half cycle / 0.5s at rated frequency, 30 x Imax
<0.1% (indirect) / 0.4% (direct) of reference current
Frequency
50 or 60 Hz ±5%
Accuracy class
Indirect Connection
Direct Connection
Reactive energy
Class C or B (EN 50470-3); or Class 0.2S (IEC 62053-22)
Class B or A (EN 50470-3); Class 1 or 2 (IEC 62053-21)
Class 0.5 or 1 or 2 (IEC 62053-23 and IEC 62053-24)
Temperature /
Environmental
I
nfluences
Operation/storage temp.
Humidity
Temperature coefficient
Ingress protection
Protection class
- 40°C ... +70°C / - 40°C ... +85°C
95% rel. humidity, non-condensing
Average value (typical): < ±0.01% / °K
IP54
Class II to IEC 62052-11
Electromagnetic
Compatibility
Surge withstand 1.2/50 µs
Insulation strength
other
Environmental conditions
6 kV (optional 12kV), Rsource = 40 Ω, and 4kV, Rsource = 2 Ω,
4 kVrms, 50 Hz, 1 min.
Conducted disturbances from 2 kHz to 150kHz acc. 61000-4-
19
MID E2
Real time clock
Accuracy
Supercap
Internal / external battery
Crystal < 5 ppm = < 3 min./year (at T= +23°C)
2 days
10 years (without main power), 15 year life time
/ external battery (optional)
Internal tariff source
Acc. EN 62052
Up to 8 tariffs, 4 seasons, weekday dependent tariff scheme
Display
Characteristics
number of digits
digit size
Read-out without power
Type: LCD liquid crystal display, back lightened
Value field: up to 8; index field: up to 7
Value field: 4 x 8 mm; index field: 3 x 6 mm
With external battery (option)
Power supply
Power supply type
Transformer based power supply or
switch power supply
P
ower consumption
(per phase)
Voltage path
Current path
Auxiliary voltage
< 1
,1
W; <
2,3
VA
(transformer power supply)
<0,65W, <1VA (wide range power supply)
<0,01W, <0.01VA
<1,9W, <4VA
Inputs and Outputs
(option)
Control- or alarm-input
S0 pulse inputs
Output (electronic)
Bistable mech. relay
Up to 2; Control voltage Us 50 – 276 V
Up to 2; acc. IEC 62053-31; Class A (max. 27 V DC)
Up to 6: 12 to 230 V AC/DC (+15%); 100 mA
Up to 1: 230 V AC (+/- 15%); 10A
Pulse
LED (test)
Type / Number
Impulse frequency / length
meter constant
LED red / 2 – function kWh / kvarh; kWh / kVAh
Programmable; max. 64Hz / 7.8 ms
Programmable
Communication
Interfaces
Optical interface
Electrical interface
Exchangeable
Communication module
Infrared, serial, half-duplex; max. 19.200 bps; DLMS
RS485, half-duplex 2 wires; max. 38.400 bps; DLMS
RS232, half-duplex 2 wires; max. 38.400 bps; DLMS
Ethernet interface (IPV4/V6)
Housing
Dimensions
Material
Environmental conditions
DIN 43857 part 2; DIN 43859
Polycarbonate (Lexan), partly glass-fiber reinforced, flame-
retardant, self-extinguishing plastic, recyclable
MID M1
Connections
Indirect Connection
Direct Connection
Auxiliary connections
Screw type terminals with cages; Diameter 5.0 mm
Pozidrive Combi No. 2; tightening torque max. 1.4 Nm
Screw type terminals with cages; Diameter 9.5 mm
Pozidrive Combi No. 2; tightening torque max. 2.5 Nm
Screw terminals 2.5mm, conductor cross section: 1.5 to 2.5mm²
Head screw size 2 (slit); tightening torque max. 1.0 Nm
Weight
Direct / Indirect Connection
1.3 / 1.2kg
Terminal cover
Standard
advanced cover
40 mm free space, height 100mm (also in transparent version)
70 mm free space, height 100mm, supporting installation of
external modem/Gateway
