MCS301 - 3ph meter Page 27 of 142
MCS301 meter - product Manual 1.25 MetCom Solutions GmbH
6.3 Display Modes
The following principles apply for display control:
Alternate button 1
• pressing briefly (<2s) switches to the next list value or menu option
• pressing for longer (2s < t < 5s) either activates the menu options currently being is
displayed or causes preceding values to be skipped
• pressing the alternate button for longer (>5 s) returns you from any display mode
back into the scroll mode (rolling display)
Alternate button 2
• pressing briefly (<2s) switches to the previous value of the selected list
• pressing the alternate button for longer (>5 s) returns you from any display mode
back into the scroll mode (rolling display)
• remark: the alternate button 2 can only be used to scroll up and down inside a
selected list
Demand Reset button (sealable)
• pressing it for any length of time, in Scroll mode only, always causes a reset
• pressing the demand reset button during the display test mode will activate the test
mode of the meter, where all energy data will be displayed with a higher resolution
Different operating modes for the display are:
• Scroll Mode
• Display test
• Display mode menu "Alternate mode"
- "Std-dAtA" Standard display mode displaying all the list's register contents
- "
Protect
Std-dAtA" display mode containg metrological relevant data
- "SEr-dAtA" Second display mode displaying all the list's register contents)
- “P.01” Load profile 1 mode displaying all load profile 1 data
- “P.02” Load profile 2 mode displaying all load profile 2 data
• Display mode menu "Reset mode"
- “tESt” High-resolution test mode for testing purposes
- “CELL connect” Activation of Push Mode to connect to HES
- “Slave InStALL” Activation of M-Bus installation
