13.3 Load profile 2 – daily profile
The load profile 2 has below characteristic:
• configurable interval, period 2: 1 … 60min, 24h
• default interval: 24h
• Max number of channels: 42
• Max. number of days per channel: 180 (24h, 42 channels)
remark: in case the number of channels is less than 42 the size for the remaining
channels is increased
• storage mode per interval
o demand values
o index values
• all energy data can be stored as tariff register as well
Selectable quantity OBIS code
1 Clock 1.0.0
2 active energy, +A 1-0:1.8.x.255
3 active energy, -A 1-0:2.8.x.255
4 reactive energy, +R 1-0:3.8.x.255
5 reactive energy, -R 1-0:4.8.x.255
6 reactive energy, R1 1-0:5.8.x.255
7 reactive energy, R2 1-0:6.8.x.255
8 reactive energy, R3 1-0:7.8.x.255
9
reactive energy
, R4
1
-
0:8.8.x
.255
10 apparent energy, +S 1-0:9.8.x.255
11 apparent energy, -S 1-0:10.8.x.255
12 iron losses, +U*U*h 1-0:83.8.4.255
13 copper losses, +I*I*h 1-0:83.8.1.255
14 iron losses, -U*U*h 1-0:83.8.5.255
15
co
pper losses,
-
I
*
I
*h
1
-
0:83.8.2.255
16 active energy, /+A/ + /-A/ 1-0:15.8.x.255
17 active energy, /+A/ - /-A/ 1-0:16.8.x.255
18 Max. demand, /+A/ + /-A/ 1-0:15.54.0.255
19 Time stamp of max. demand, /+A/ + /-A/ 1-0:15.54.0.255
20 Max. demand, /+A/ 1-0:1.54.0.255
21 Time stamp of max. demand, /+A/ 1-0:1.54.0.255
22 Error register 0-0:97.97.1.255
23 Alarm register 1 0-0:97.98.0.255
24 Alarm register 2 0-0:97.98.1.255
Table 29: load profile 2 data – daily profile (x=0 … 8 max)
