MCS301 - 3ph meter Page 38 of 142

MCS301 meter - product Manual 1.25 MetCom Solutions GmbH

8.3.3 Instantaneous measurement data – PQ data with harmonics + THD

Below data are supported as instantaneous PQ data including harmonics and THD

L1 L2 L3

0 1. te harmonic, voltage *) 1-0:32.7.1 1-0:52.7.1 1-0:72.7.1

1 3.te harmonic, voltage 1-0:32.7.3 1-0:52.7.3 1-0:72.7.3

2 5.te harmonic, voltage

1-0:32.7.5 1-0:52.7.5 1-0:72.7.5

3 7.te harmonic, voltage

1-0:32.7.7 1-0:52.7.7 1-0:72.7.7

4 9.te harmonic, voltage

1-0:32.7.9 1-0:52.7.9 1-0:72.7.9

5 11.te harmonic, voltage

1-0:32.7.11 1-0:52.7.11 1-0:72.7.11

6 13.te harmonic, voltage

1-0:32.7.13 1-0:52.7.13 1-0:72.7.13

8 15.te harmonic, voltage

1-0:32.7.15 1-0:52.7.15 1-0:72.7.15

0 1.te harmonic, current *) 1-0:31.7.1 1-0:51.7.1 1-0:71.7.1

9 3.te harmonic, current 1-0:31.7.3 1-0:51.7.3 1-0:71.7.3

10 5.te harmonic, current 1-0:31.7.5 1-0:51.7.5 1-0:71.7.5

11 7.te harmonic, current

1-0:31.7.7 1-0:51.7.7 1-0:71.7.7

12 9.te harmonic, current

1-0:31.7.9 1-0:51.7.9 1-0:71.7.9

13 11.te harmonic, current

1-0:31.7.11 1-0:51.7.11 1-0:71.7.11

13 13.te harmonic, current

1-0:31.7.13 1-0:51.7.13 1-0:71.7.13

14 15.te harmonic, current 1-0:31.7.15 1-0:51.7.15 1-0:71.7.15

15 THD, voltage 1-0:32.7.124 1-0:52.7.124 1-0:72.7.124

16 THD, current 1-0:31.7.124 1-0:51.7.124 1-0:71.7.124

Table 8:

list

of instantaneous PQ data with harmonics and THD

*) available with MCOR FW 1-0:01.01.25

Metcom Solutions MCS301 - Instantaneous Measurement Data - PQ Data with Harmonics + THD
