8 Measurement data
8.1 Energy measurement
Below energy register should be configurable, with below features
• up to 16 different type of energy register (configurable)
• up to 8 energy tariffs
• > 15 historical set of data (see billing profile)
• resolution on communication interface (9,x) number of decimals: x=0…4
• resolution on LCD (8,x) number of decimals: x=0…4
8.1.1 Energy measurement (3ph values)
Below energy register data are supported, including tariff register
Energy register total Tariff 1 … Tariff 8
1 active energy, +A 1-0:1.8.0.255 1-0:1.8.1.255 1-0:1.8.8.255
2 active energy, -A 1-0:2.8.0.255 1-0:2.8.1.255 1-0:2.8.8.255
3 reactive energy, +R 1-0:3.8.0.255 1-0:3.8.1.255 1-0:3.8.8.255
4 reactive energy, -R 1-0:4.8.0.255 1-0:4.8.1.255 1-0:4.8.8.255
5 reactive energy, R1 1-0:5.8.0.255 1-0:5.8.1.255 1-0:5.8.8.255
6 reactive energy, R2 1-0:6.8.0.255 1-0:6.8.1.255 1-0:6.8.8.255
7 reactive energy, R3 1-0:7.8.0.255 1-0:7.8.1.255 1-0:7.8.8.255
8 reactive energy, R4 1-0:8.8.0.255 1-0:8.8.1.255 1-0:8.8.8.255
9 apparent energy, +S 1-0:9.8.0.255 1-0:9.8.1.255 1-0:9.8.8.255
10 apparent energy, -S 1-0:10.8.0.255 1-0:10.8.1.255 1-0:10.8.8.255
11 Absolue active energy, /+A/ + /-A/ 1-0:15.8.0.255 1-0:15.8.1.255 1-0:15.8.8.255
12 Net active energy, /+A/ - /-A/ 1-0:16.8.0.255 1-0:16.8.1.255 1-0:16.8.8.255
13 line losses, +U*U*h 1-0:83.8.1.255
14 Line losses, -U*U*h 1-0:83.8.2.255
15 transformer losses, +I*I*h 1-0:83.8.4.255
16 Transformer losses, -I*I*h 1-0:83.8.5.255
17
Transformer losses, /U*U*h/ with
normalized R FE =1MOhm *)
1-0:83.8.19.255
18
line losses, /I*I*h/ with normalized
R cu =1Ohm *)
1-0:83.8.20.255
Table 2: list of 3ph energy register with OBIS codes (ACOR FW02.02.11)
