MCS301 - 3ph meter Page 53 of 142
MCS301 meter - product Manual 1.25 MetCom Solutions GmbH
13 Load profile
Load profile captures and stores several parameters (defined as channels), at specified time
intervals. In case of changing any of the capture objects or time interval (capture period) of
the load profile, the load profile is reset. The following types of profiles are provided:
•
Load Profile 1 (e.g. 1h or 15min load profile) (1-0:99.1.0.255);
•
Load Profile 2 (e.g. daily load profile) (1-0:99.2.0.255);
•
Average Values Profile (1-0:99.133.0.255);
•
Max. Values Profile (1-0:99.134.0.255);
•
Min. Values Profile (1-0:99.135.0.255);
•
Harmonics Profile (1-0:99.136.0.255);
•
M-Bus Load Profile Channel 1 (Water meter) (0-1:24.3.0.255);
•
M-Bus Load Profile Channel 2 (Gas meter) (0-2:24.3.0.255);
•
M-Bus Load Profile Channel 3 (Reserved) (0-3:24.3.0.255);
•
M-Bus Load Profile Channel 4 (Irrigation meter) (0-4:24.3.0.255);
Two additional readout profiles with up to 42 entries for instantaneous values of energy and
power quality at the reading time are supported through the reading client.
•
Energy Instantaneous Values (7, 0-0:21.0.6.255);
•
Power Quality Instantaneous Values (7, 0-0:21.0.5.255);
13.1 General profile Structure
All Load Profiles have the same structure. The different values (register) can be stored by
each Load Profile COSEM object including capture time (as timestamp) and their status
(Profile Status of relevant profile object). The status shows the situation of critical events
during capturing of values.
Time Stamp Status Channel 1 Channel 2 …. Channel n
2016-12-15, 00:15:00 08 1234567 4561 …. 981234
2016-12-15, 00:30:00 08 1234588 4563 …. 981301
2016-12-15, 00:40:00 08 1234592 4566 …. 981387
13.1.1 Sort method
The buffer may be defined as sorted by one of the capture objects (values e.g. the clock). For
all profile generic objects, the FIFO method is used. In case of changing sorting method, the
load profile will be reset.
