MCS301 - 3ph meter Page 23 of 142
MCS301 meter - product Manual 1.25 MetCom Solutions GmbH
5.5 Name plate
The MCS301 nameplate is laser printed on the meter cover:
- Property Number - Accuracy Class
- Serial Number - LED test pulse constants RA and RL
- Manufacturer (name and address) - Meter and consumption type
- Model type - Symbol for degree of protection
- Year of manufacture - Identifier system
- Conformity symbol
- Rated voltage
- Rated/Limit current
- Rated frequency
- CT/VT ratio
Figure 11: Nameplate of the meter
