MCS301 - 3ph meter Page 51 of 142
MCS301 meter - product Manual 1.25 MetCom Solutions GmbH
12 Data Model and protocol
12.1 Data model
Below data model and identification system are supported from the meter
• Identification system
The MCS301 meter is using the OBIS identification system according EN 62056-61
• Data model
Below data model are supported
• IDIS package 2 and 3
• More details are described in MetCom object list
12.2 Protocol
The meter support different option for communication, which are configurable by the user
12.2.1 DLMS protocol only
In this application the meter is using only the DLMS protocol for communication according
the Green book V8.1 and blue book V12.1.
In that mode all reading and writing procedures are done by the DLMS protocol. No Mode E
command is supported.
Remark: The starting baud rate on the optical interface is 9.600 / 19.200 Baud
