MCS301 - 3ph meter Page 37 of 142
MCS301 meter - product Manual 1.25 MetCom Solutions GmbH
8.3 Instantaneous measurement
8.3.1 Instantaneous measurement – demand data
Below demand data are supported as instantaneous demand data
Total L1 L2 L3
1 active demand, +P 1-0:1.7.0.255 1-0:21.7.0.255 1-0:41.7.0.255 1-0:41.7.0.255
2 active demand, -P 1-0:2.7.0.255 1-0:22.7.0.255 1-0:42.7.0.255 1-0:62.7.0.255
3 active demand, /+P/ + /-P/ 1-0:15.7.0.255
4 reactive demand, +Q 1-0:3.7.0.255 1-0:23.7.0.255 1-0:43.7.0.255 1-0:63.7.0.255
5 reactive demand, -Q 1-0:4.7.0.255 1-0:24.7.0.255 1-0:44.7.0.255 1-0:64.7.0.255
6 reactive demand, Q1 *) 1-0:5.7.0.255
7 reactive demand, Q2, *) 1-0:6.7.0.255
8 reactive demand, Q3, *) 1-0:7.7.0.255
9 reactive demand, Q4, *) 1-0:8.7.0.255
10
apparent demand, +S 1-0:9.7.0.255 1-0:29.7.0.255 1-0:49.7.0.255 1-0:69.7.0.255
11
apparent demand, -S 1-0:10.7.0.255 1-0:30.7.0.255 1-0:50.7.0.255 1-0:70.7.0.255
Table 6: list of instantaneous demand data with OBIS codes
*) available with ACOR FW 1-0:02.02.11
8.3.2 Instantaneous measurement data – PQ data without harmonics
Below data are supported as instantaneous PQ data without harmonics
Instantaneous data total L1 L2 L3
1 Voltage 1-0:32.7.0.255 1-0:52.7.0.255 1-0:72.7.0.255
2 Current 1-0:31.7.0.255 1-0:51.7.0.255 1-0:71.7.0.255
3 Current, sum of all phases
1-0:90.7.0.255
4 Power factor 1-0:13.7.0.255 1-0:33.7.0.255 1-0:53.7.0.255 1-0:73.7.0.255
5 phase angle, ref U1 1-0:81.7.0.255 1-0:81.7.10.255 1-0:81.7.20.255
6 Current angle, Ux-Ix 1-0:81.7.4.255 1-0:81.7.15.255 1-0:81.7.26.255
6 Current angle, Ix-Ux 1-0:81.7.40.255
1-0:81.7.51.255 1-0:81.7.62.255
7 frequency in any phase 1-0:14.7.0.255
8 Neutral current calculation 1-0:91.7.3.255
9 Internal temperature 0-0:96.9.0.255
Table 7: list of instantaneous PQ data without harmonics
